A strong first impression with features and design that are second to none.
Whether you operate a small shop, supermarket or hypermarket, Linkool is the efficient counter solution you need to put your products in the spotlight. Linkool combines important features with a wide transparent tempered glass design, stable temperature performance, and a wide range of lighting solutions and accessories. It’s a versatile solution designed to make a strong first impression – which ultimately leads to strong sale.
Standard Features: Optional:
– Full body thicker foam,Effectively isolate external heat – LED light color
– Bright led light bar and eye-catching top light box design – Shelf
– Powerful refrigeration with high-quality compressor – Sticker
– Digital temperature control
– Anti-rodent board design
– Low noise
– Double-layer insulated insulating glass
– Built-in water tray and Drain hole design
– Adjustable shelving.
– 6 strong casters, easy move .
Technical parameter:
| 1.Basic Spec | Export Model | KXD-750 | KXD-1253 | KXD-1880 | KXD-2500 |
| Voltage/frequency | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | |
| Refrigerant | R290a/R404a | R290a/R404a | R290a/R404a | R290a/R404a | |
| Foaming agent | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | |
| Max Ambient | 25℃ at 60%RH | 25℃ at 60%RH | 25℃ at 60%RH | 25℃ at 60%RH | |
| Inner temperature | -18℃ to -22℃ | -18℃ to -22℃ | -18℃ to -22℃ | -18℃ to -22℃ | |
| Volume | 560 | 930 | 1450 | 1940 | |
| Product Dimension W*D*H (mm) | 750*760*1997 | 1253*760*1997 | 1880*760*1997 | 2508*760*2092 | |
| Packing Dimension W*D*H(mm) | 775*780*2090 | 1278*780*2090 | 1905*780*2090 | 2533*760*2220 | |
| Net weight(kg) | 150 | 240 | 305 | 445 | |
| Gross weight(kg) | 158.5 | 270 | 355 | 500 | |
| Container Loads 40GP/ 40HQ | 45 | 27 | 18 | 12 | |
| 2. Aesthetics | Door type | 1 Hinge | 2 Hinge | 3 Hinge | 4 Hinge |
| Glass door | Trible-pane tempered glass door with heating film | Trible-pane tempered glass door with heating film | Trible-pane tempered glass door with heating film | Trible-pane tempered glass door with heating film | |
| Cabinet | White, painted steel | White, painted steel | White, painted steel | White, painted steel | |
| Interior | White, painted aluminum walls | White, painted aluminum walls | White, painted aluminum walls | White, painted aluminum walls | |
| Color&Branding | Optional | Optional | Optional | Optional | |
| Cooling system | Fan cooling | Fan cooling | Fan cooling | Fan cooling | |
| Defrosting | Automatic | Automatic | Automatic | Automatic | |
| Evaporator | copper fin block | copper fin block | copper fin block | copper fin block | |
| Evaporator fan motor | 1×EMB | 2×EMB | 2×EMB | 3×EMB | |
| Condenser | Steel wire | Steel wire | Steel wire | Steel wire | |
| Condenser fan motor | 1×EMB | 2×EMB | 2×EMB | 3×EMB | |
| Light | 2 cabinet lights, LED | 3 cabinet lights, LED | 4 cabinet lights, LED | 1 canopy light+ 5 cabinet lights, LED | |
| Light switch | Yes | Yes | Yes | Yes | |
| Temperature controller | Digital | Digital | Digital | Digital | |
| 4. Others | Water tray | Self-evaporation | Self-evaporation | Self-evaporation | Self-evaporation |
| Castor | 4 castors, front 2 with brakes | 4 castors, front 2 with brakes | 4 castors, front 2 with brakes | 8 castors, front 2 with brakes | |
| Shelf (Material/Qty) | Epoxy coated wire shelves / 5 | Epoxy coated wire shelves / 10 | Epoxy coated wire shelves / 15 | Epoxy coated wire shelves / 20 | |
| K clips and shelf support liners | 304 Stainless steel | 304 Stainless steel | 304 Stainless steel | 304 Stainless steel | |
| Price tag | No | No | No | No | |
| Light box | No | No | No | No | |
| Lock & key | No | No | No | No |
Fan Dynamic Cooling
Fan cooling system/ventilator
cooling/Dynamic cooling/Forced air
circulation, Hot gas Auto- defrost
Heavy Duty Shelves
Adjustable for merchandising; 30 kg Load endurance / shelf
5 pieces per door of PVC shelf,
The upright display fridge.efficient and stylish,enhances supermarkets.convenience stores,and bars.It keeps perishables fresh in
supermarkets.organizes beverages in convenience stores,and attracts patrons in bars,boosting sales and customer satisfaction.
Linkool is an internationally operating manufacturer of commercial refrigeration company, Lincool(Zhongshan) Electrical equipment
leading innovator of temperature-controlled food di
