The new vertical freezer brings together all of the features needed for the ultimate shopping experience – all in perfect harmony. Advanced, integrated LED illumination and a large display area allow for attractive, uninhibited presentation of multiple product segments, with premium products on top shelves and bulk products in the bottom basket. The ergonomic design also facilitates easy product loading for store staff, and features like a unique double door system and elaborated air management help ensure the perfect balance of performance and efficiency.
Energy efficiency. Optimal merchandising. Minimal footprint. Linkool LXG+ has it all covered.
Increased food protection with reduced Enhanced merchandising
energy costs
－New Temperature Equalizer System －Pure, unobtrusive design
－Digital temperature controller －Generous product-facing area
－Fewer defrost cycles －Aluminium frame and decoration
－Higher evaporating temperature －Improved LED illumination
－Energy-efficient EC fans －Multi-layered shelf can be combined freely
－Multi-direction refrigeration technology －Enhanced visibility of merchandise
－Reduced refrigeration load
Technical parameter:
| 1.Basic Spec | Export Model | LXG-750 | LXG-1253 | LXG-1880 | LXG-2500 |
| Voltage/frequency | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | |
| Refrigerant | R290/R134a | R290/R134a | R290/R134a | R290/R134a | |
| Foaming agent | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | |
| Max Ambient | 38℃ at 65%RH | 38℃ at 65%RH | 38℃ at 65%RH | 38℃ at 65%RH | |
| Inner temperature | 1℃ to 8℃ | 1℃ to 8℃ | 1℃ to 8℃ | 1℃ to 8℃ | |
| Volume | 600 | 1000L | 1530 | 2060 | |
| Product Dimension W*D*H (mm) | 750*710*1997 | 1253*710*1997 | 1880*710*1997 | 2508*710*1997 | |
| Packing Dimension W*D*H(mm) | 775*760*2090 | 1278*760*2090 | 1905*760*2090 | 2533*760*2090 | |
| Net weight(kg) | 130 | 179 | 207.5 | 360 | |
| Gross weight(kg) | 141.5 | 197 | 235 | 400 | |
| Container Loads 40GP/ 40HQ | 45 | 27 | 18 | 12 | |
| 2. Aesthetics | Door type | 1 Hinge | 2 Hinge | 3 Hinge | 4 Hinge |
| Glass door | Double-pane with one tempered low-E coated glass door | Double-pane with one tempered low-E coated glass door | Double-pane with one tempered low-E coated glass door | Double-pane with one tempered low-E coated glass door | |
| Cabinet | White, painted steel | White, painted steel | White, painted steel | White, painted steel | |
| Interior | White, painted aluminum walls | White, painted aluminum walls | White, painted aluminum walls | White, painted aluminum walls | |
| Color&Branding | Optional | Optional | Optional | Optional | |
| Cooling system | Fan cooling | Fan cooling | Fan cooling | Fan cooling | |
| Defrosting | Automatic | Automatic | Automatic | Automatic | |
| Evaporator | Aluminium fin block | Aluminium fin block | Aluminium fin block | Aluminium fin block | |
| Evaporator fan motor | 1×EMB | 1×EMB | 2×EMB | 3×EMB | |
| Condenser | Steel wire | Steel wire | Steel wire | Steel wire | |
| Condenser fan motor | 1×EMB | 2×EMB | 2×EMB | 4×EMB | |
| Light | 2 cabinet lights, LED | 3 cabinet lights, LED | 4 cabinet lights, LED | 5 cabinet lights, LED | |
| Light switch | Yes | Yes | Yes | Yes | |
| Temperature controller | Digital | Digital | Digital | Digital | |
| 4. Others | Water tray | Self-evaporation | Self-evaporation | Self-evaporation | Self-evaporation |
| Castor | 4 castors, front 2 with brakes | 4 castors, front 2 with brakes | 4 castors, front 2 with brakes | 8 castors, front 2 with brakes | |
| Shelf (Material/Qty) | Epoxy coated wire shelves / 5 | Epoxy coated wire shelves / 10 | Epoxy coated wire shelves / 15 | Epoxy coated wire shelves / 20 | |
| K clips and shelf support liners | 304 Stainless steel | 304 Stainless steel | 304 Stainless steel | 304 Stainless steel | |
| Price tag | No | No | No | No | |
| Light box | NO | NO | NO | NO | |
| Lock & key | No | No | No | No |
