Increased food protection with reduced Enhanced presentation of merchandise
energy costs
－New Temperature Equalizer System －Pure, unobtrusive design
－Digital temperature controller －Generous product-facing area
－Fewer defrost cycles －Aluminium frame and decoration
－Higher evaporating temperature －Improved LED illumination
－Energy-efficient EC fans －Multi-layered shelf can be combined freely
－Multi-direction refrigeration technology －Enhanced visibility of merchandise
－Reduced refrigeration load
Anti-frost design Simplified maintenance
－Auto defrost system －Numbered keybars for fast and flexible shelf fitting
－Hygienic and easy-to-clean design
Technical parameter:
| Export Model | KLG-750 | KLG-1253 | KLG-1880 | KLG-2500 |
| Voltage/frequency | 220V/50Hz | 220V/50HZ | 220V/50HZ | 220V/50HZ |
| Refrigerant | R290/R134a | R290/R134a | R290/R134a | R290/R134a |
| Foaming agent | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness | Cyclopentane,60MM thickness |
| Max Ambient | 38℃ at 65%RH | 38℃ at 65%RH | 38℃ at 65%RH | 38℃ at 65%RH |
| Inner temperature | 1℃ to 8℃ | 1℃ to 8℃ | 1℃ to 8℃ | 1℃ to 8℃ |
| Volume | 600 | 1000L | 1530 | 2060 |
| Product Dimension W*D*H (mm) | 750*710*1997 | 1253*750*2092 | 1880*750*2092 | 2508*750*2092 |
| Packing Dimension W*D*H(mm) | 775*760*2090 | 1278*760*2220 | 1905*760*2220 | 2533*760*2220 |
| Net weight(kg) | 130 | 172 | 242 | 355 |
| Gross weight(kg) | 141.5 | 202 | 282 | 410 |
| Container Loads 40GP/ 40HQ | 45 | 27 | 18 | 12 |
| Door type | 1 Hinge | 2 Hinge | 3 Hinge | 4 Hinge |
| Glass door | Double-pane with one tempered low-E coated glass door | Double-pane with one tempered low-E coated glass door | Double-pane with one tempered low-E coated glass door | Double-pane with one tempered low-E coated glass door |
| Cabinet | White, painted steel | White, painted steel | White, painted steel | White, painted steel |
| Interior | White, painted aluminum walls | White, painted aluminum walls | White, painted aluminum walls | White, painted aluminum walls |
| Color&Branding | Optional | Optional | Optional | Optional |
| Cooling system | Fan cooling | Fan cooling | Fan cooling | Fan cooling |
| Defrosting | Automatic | Automatic | Automatic | Automatic |
| Evaporator | Aluminium fin block | Aluminium fin block | Aluminium fin block | Aluminium fin block |
| Evaporator fan motor | 1×EMB | 1×EMB | 2×EMB | 3×EMB |
| Condenser | Steel wire | Steel wire | Steel wire | Steel wire |
| Condenser fan motor | 1×EMB | 1×EMB | 1×EMB | 2×EMB |
| Light | 2 cabinet lights, LED | 1 canopy light+ 2 cabinet lights, LED | 1 canopy light+ 4 cabinet lights, LED | 1 canopy light+ 4 cabinet lights, LED |
| Light switch | Yes | Yes | Yes | Yes |
| Temperature controller | Digital | Digital | Digital | Digital |
| Water tray | Self-evaporation | Self-evaporation | Self-evaporation | Self-evaporation |
| Castor | 4 castors, front 2 with brakes | 4 castors, front 2 with brakes | 4 castors, front 2 with brakes | 8 castors, front 2 with brakes |
| Shelf (Material/Qty) | Epoxy coated wire shelves / 5 | Epoxy coated wire shelves / 10 | Epoxy coated wire shelves / 15 | Epoxy coated wire shelves / 20 |
| K clips and shelf support liners | 304 Stainless steel | 304 Stainless steel | 304 Stainless steel | 304 Stainless steel |
| Price tag | No | No | No | No |
| Light box | NO | Yes | Yes | Yes |
| Lock & key | No | No | No | No |
